Introduction:

Tungsten wire mesh is special due to the metal used. With purity more than 99.9% Tungsten is a greyish white refractory metal, has the highest tensile strength among all metals. The metal has the highest melting point and the lowest vapor pressure. Tungsten is extracted from ores, crushed to become powdery and thereafter mixed and molded to create the wire mesh.

Specification

1.Material: Tungsten Wire
2.Color: Black Grey
3.Transport Package: Wooden case, also can pack as customers’ request
4.Types: Flash edge tungsten woven mesh, wrapped edge tungsten woven mesh.
5.Hole pattern: Square hole, rectangle hole.
6.Wire diameter:0.053-0.6mm
7.Screen Size: 10-200mesh
8.Mesh width: 10mm-2000mm
9.Mesh length:1-100m
10.Delivery time:15 days after your confirmation


Mesh Count Wire Diameter（mm） Aperture（mm） Max Width（m）
10 0.60 1.94 1.60
20 0.40 0.87 1.60
30 0.30 0.55 1.60
40 0.23 0.40 1.60
50 0.20 0.31 1.60
60 0.15 0.27 1.60
70 0.12 0.24 1.60
80 0.13 0.19 1.60
90 0.12 0.16 1.60
100 0.10 0.15 1.60
120 0.09 0.12 1.60
150 0.063 0.11 1.60
180 0.053 0.01 1.60
200 0.053 0.07 1.60

Feature

1. Highest melting point – over 1650C at high temperature
2. Melting point of 3410C
3. Low vapor pressures at high temperature
4. Electrical and thermal conductivity
5. Low coefficient thermal expansion
6. High density
7. High tensile strength at extreme temperature
