Introduction:

Stainless Steel Rope Mesh, also known as cable mesh, animal zoo mesh, bird mesh, and fence mesh, is made from high-quality stainless steel materials like 304, 316, or 316L. Resistant to corrosion and UV rays, it thrives in harsh environments, offering durability and cost-effectiveness. Its standout features include resilience and flexibility, available in knotted or ferrule types with cruciate/cross clamps, favored by fashion architects for their versatility and aesthetics.

Specification

struct ure of wire wire rope diameter aperture
inch mm inch mm
7*19 1/8 3.2 4.75*4.75 120*120
7*19 1/8 3.2 4*4 102*102
7*19 1/8 3.2 3.55*3.55 90*90
7*19 1/8 3.2 3*3 76*76
7*19 1/8 3.2 2*2 51*51
7*17 3/32 2.4 4*4 102*102
7*17 3/32 2.4 3.55*3.55 90*90
7*17 3/32 2.4 3*3 76*76
7*17 3/32 2.4 2.4*2.4 60*60
7*17 3/32 2.4 2*2 51*51
7*17 5/64 2 3*3 76*76
7*17 5/64 2 2.4*2.4 60*60
7*17 5/64 2 2*2 51*51
7*17 5/64 2 1-1/2*1-1/2 38*38
7*17 1/16 1.6 3*3 76*76
7*17 1/16 1.6 2.4*2.4 60*60
7*17 1/16 1.6 2*2 51*51
7*17 1/16 1.6 1-1/2*1-1/2 38*38
7*17 1/16 1.6 1.2*1.2 30*30
7*17 1/16 1.6 1*1 25.4*25.4
7*17 3/64 1.2 2*2 51*51
7*17 3/64 1.2 1-1/2*1-1/2 38*38
7*17 3/64 1.2 1.2*1.2 30*30
7*17 3/64 1.2 1*1 25.4*25.4
7*17 3/64 1.2 4/5*4/5 20*20

Feature

  • High strength.
  • Strong toughness.
  • Free-angles bending.
  • Structures flexible.


Application

 Stainless Steel Rope Mesh

Office

 Stainless Steel Rope Mesh

Scenic

Stainless Steel Rope Mesh

Residential


Stainless Steel Rope Mesh

Mall

Stainless Steel Rope Mesh

seaside
