Knitted mesh

Knitted mesh Knitted mesh Knitted mesh Knitted mesh Knitted mesh Knitted mesh
Knitted mesh Knitted mesh   Knitted mesh   Knitted mesh Knitted mesh Knitted mesh


Introduction:

Knitted mesh, as its name implies, is a metal wire or plastic strand knitted into an interlocking looped mesh structure, the same way as stockings and should not be confused with woven mesh, which is the form of rectangular openings of parallel wires.  The knitted mesh has a flexibility not possessed by the woven mesh, due to the loops being able to move relative to each other thereby giving a two-way stretch.  This flexibility gives knitted mesh a unique advantage for many industrial uses.

Specification

Material stainless steel wire 304, 304L, 316, 316 L, galvanized wire, brass wire, copper wire,  titanium wire, alloy wire, nickel wire, nylon wire, PE wire, fiberglass wire, etc
Wire Diameter Round wire 0.08-0.55mm
Flat wire 0.1*0.4mm,0.1*0.3mm,0.2*0.4mm
Hole Size 4mm×3mm  5mm×6mm  2mmx4mm, 4mmx5mm etc.
Width 40mm, 80mm, 100mm, 150mm, 200mm, 300mm, 400mm, 500 mm, 600mm, etc.
Length 30-200m
Wire Number Single wire , double wires, several wires.
Mesh type Standard type 40-100 60-150 105-300 140-400
Highly efficiency type 60-100 80-100 80-150 90-150 150-300 200-400
Damping type 30-50 48-50 30-60 30-80 50-120
Packing With carton or wooden box



Feature

1.High strength and stability.
2.High filtration efficiency.
3.Good shielding performance.
4.Corrosion and rust resistance.
5.Durable and long service life
